Electrolytic HTE Copper Foil thickness 35um For PCB Laminate / Multi Layer Printed Circuit Boards

Electrolytic HTE Copper Foil thickness 35um For PCB Laminate / Multi Layer Printed Circuit Boards

    • Electrolytic HTE Copper Foil thickness 35um For PCB Laminate / Multi Layer Printed Circuit Boards
  • Electrolytic HTE Copper Foil thickness 35um For PCB Laminate / Multi Layer Printed Circuit Boards

    Thông tin chi tiết sản phẩm:

    Place of Origin: China
    Hàng hiệu: JIMA
    Chứng nhận: SGS, ISO,Reach, RoHS
    Model Number: EDCU-HC

    Thanh toán:

    Minimum Order Quantity: 200kg
    Giá bán: negotiation
    Packaging Details: Standard wooden carton
    Delivery Time: 5-25days
    Payment Terms: T/T, L/C
    Supply Ability: 1000 Ton per month
    Tiếp xúc
    Chi tiết sản phẩm
    Purity: 99.95% Thickness: 70um,35um
    Color: red or black Standard: IPC-4562
    Inter Diameter: 76 Mm,152 Mm, 3 Inch,6 Inch products name: Electrolytic HTE Copper Foil with thickness 35um For PCB laminate Multi-layer printed circuit boards Multi-layer PCB
    high temperature elongation copper foil: 120 min (180 °C in Atmosphere)
    Điểm nổi bật:

    roll of copper foil

    ,

    electrodeposited copper foil

    Electrolytic HTE Copper Foil with thickness 35um For PCB laminate Multi-layer printed circuit boards Multi-layer PCB



    Detail Specification:

    Single side treatment in red. and single Side Shiny
    Thickness: 70um and 35um
    Width range: 5-1380mm,and standard width:1290mm,max 1380mm width

    high temperature elongation copper foil :120 min (180 °C in Atmosphere)

    Internal diameter: 3 inch/6 inch.
    Standard :IPC-4562



    Classify:



    1.(STD-E)- standard electrodeposited copper foil.

    2.(HD-E)-high ductility electrodeposited copper foil.

    3.(HTE-E)-high temperature elongation electrodeposited copper foil.



    Copper foil Application


    Application 2>PCB manufacture
      3>antenna PCB


    4>PCB laminate

    5>Multi-layer printed circuit boards/Multi-layer PCB



    Features and advantages

    1.The thermally stable microstructures with their stable mechanical properties

    2. Improve dimensional stability

    3.Reduce bulging, warping and nail head formation.

    These resist thermal outliers which typically occur during laminates.




    HTE ED copper foil Technical Terms (high elongation copper foil at high temperature).

    Thickness um 18 25 35 70

    IPC 4562

    4.6.3.1

    Area weight g/m² 153± 215±5 285±5 585±8

    IPC 4562

    4.6.3.2

    Roughness (RA) μm 0.2-0.4 0.2-0.4 0.2-0.4 0.2-0.4

    IPC 4562

    4.6.9

    (RZ) μm <8.0 <9.0 ≤10.0 <15



    Copper≧

    % 99.8

    IPC 4562

    4.6.3.1

    Tensile Strength state normal Mpa >300 >300 >300 >280

    IPC 4562

    4.6.4

    state temper (180℃) Mpa >18.0 >18.0 >18.0 >18.0
    ElongationI state normal % >5.0 >6.0 >10.0 >10.0

    IPC 4562

    3.5.3

    state temper (180℃) % >2.5 >3.0 >5.0 >5.0
    Peel strength N/mm >1.35 >1.70 >1.8 >2.0

    IPC 4562

    4.6.7

    High temperature oxidation resistance(200℃,

    40min)

    No color change Standard
    Solderability Good Standard
    Solderability Good

    IPC 4562

    4.6.12

    3. Standard Width,1290(±1)mm,May according to the customer request tailor.





    Package detail:wooden box

    Electrolytic HTE Copper Foil thickness 35um For PCB Laminate / Multi Layer Printed Circuit Boards 0

    RFQ:
    Q1: What's your guarantee?
    A: All our products have 6 months guarantee after received goods, if any quality problem can contact us.

    Q2: What's your delivery time ?
    A: The common delivery time is 5-25working days. depend on your order quanity

    Q4: Can you supply the sample?
    A: Yes,We can

    Q5. Do you test all your goods before delivery?
    A: Yes, we have 100% test before delivery.

    Q6. Can you cut into size as request?
    Yes, we can.

    Q9. Can we come to China visit factory ?
    Yes ,you can .
